PKM7117KW

DC to DC Converter by Flex Power Modules (365 more products)
Download Datasheet Request Quote

Note : Your request will be directed to Flex Power Modules.

PKM7117KW Image

The PKM7117KW from Flex Power Modules is a DC to DC Converter with Input Voltage 14 to 160 V, Output Voltage 1 12.42 to 15.18 V, Output Current 1 7.25 A, Output Power 100000 mW, Isolation Voltage 1500 to 4000 Vdc. Tags: Through Hole, Buck-Boost. More details for PKM7117KW can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PKM7117KW
  • Manufacturer
    Flex Power Modules
  • Description
    12.42 to 15.18 V, 7.25 A, Buck-Boost DC to DC Converter

General

  • Type
    Buck-Boost
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    14 to 160 V
  • Output Voltage 1
    12.42 to 15.18 V
  • Output Current 1
    7.25 A
  • Output Power
    100000 mW
  • Isolation Voltage
    1500 to 4000 Vdc
  • Efficiency
    0.89
  • Operating Temperature
    -40 to 110 Degree C
  • Industry
    Industrial
  • Package Type
    Through Hole
  • Application
    Railway
  • Dimension
    57.91×36.8×12.7 mm, 2.28×1.45×0.5 in
  • Capacitance
    10 to 9000 µF
  • Regulation
    -50 to 50 mV (Line), '-50 to 50 mV (Load)
  • Ripple Voltage
    170 to 200 mVpp
  • ROHS
    Yes
  • Storage Temperature
    -55 to 125 Degree C
  • Note
    PKM-W series
