FQD5N15

Download Datasheet Request Quote

Note : Your request will be directed to onsemi.

FQD5N15 Image

The FQD5N15 from onsemi is a MOSFET with Continous Drain Current 4.3 A, Drain Source Resistance 620 to 800 milliohm, Drain Source Breakdown Voltage 150 V, Gate Source Voltage -25 to 25 V, Gate Source Threshold Voltage 2 to 4 V. Tags: Surface Mount. More details for FQD5N15 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    FQD5N15
  • Manufacturer
    onsemi
  • Description
    150 V, 5.4 to 7 nC, N-Channel Enhancement Mode MOSFET

General

  • Types of MOSFET
    N-Channel Enhancement Mode
  • Transistor Polarity
    N-Channel
  • Number of Channels
    Single
  • Continous Drain Current
    4.3 A
  • Drain Source Resistance
    620 to 800 milliohm
  • Drain Source Breakdown Voltage
    150 V
  • Gate Source Voltage
    -25 to 25 V
  • Gate Source Threshold Voltage
    2 to 4 V
  • Gate Charge
    5.4 to 7 nC
  • Power Dissipation
    30 W
  • Temperature operating range
    -55 to 150 Degree C
  • Industry
    Commercial, Industrial
  • Package Type
    Surface Mount
  • Package
    DPAK
