DIO20321SO8

Power Operational Amplifier by Dioo Microcircuits (125 more products)
Download Datasheet Request Quote

Note : Your request will be directed to Dioo Microcircuits.

DIO20321SO8 Image

The DIO20321SO8 from Dioo Microcircuits is a Power Operational Amplifier with Supply Voltage 2.5 to 5.5 V, Input Offset Voltage ±3.5 mV, Input Bias Current 1 to 10 pA, Quiescent Current 350 uA, Input Offset Current 1 to 10 pA. Tags: Surface Mount, General Purpose Op Amp. More details for DIO20321SO8 can be seen below.

Product Specifications

Product Details

  • Part Number
    DIO20321SO8
  • Manufacturer
    Dioo Microcircuits
  • Description
    2.5 to 5.5 V, 350 uA, Power operational Amplifier

General

  • Type
    General Purpose Op Amp
  • Number of Channel
    Single
  • Supply Voltage
    2.5 to 5.5 V
  • Input Offset Voltage
    ±3.5 mV
  • Input Bias Current
    1 to 10 pA
  • Quiescent Current
    350 uA
  • Input Offset Current
    1 to 10 pA
  • Input Offset Voltage Drift
    2.7 µV/°C
  • Input Voltage Noise
    12 to 20 nV/vHz
  • Output Current
    45 to 48 mA
  • Output Voltage Swing
    0.015 to 0.1 V
  • Open Loop Gain
    92 to 110 dB
  • Gain Bandwidth
    6 MHz
  • CMRR
    66 to 90 dB
  • PSRR
    70 to 94 dB
  • Slew Rate
    3.6 V/us
  • Operating Temperature
    -40 to 125 Degree C
  • Storage Temperature
    -65 to 150 Degree C
  • RoHS Compliance
    Yes
  • Industry
    Industrial, Commercial
  • Application
    Audio Output, Sensor Interface, Ative Filters, A/D Converters, Cellular and Cordless Phones, Laptops and PDAs, Photodiode Amplification, Battery-Powered Instrumentation
  • Package
    SOIC-8
  • Package Type
    Surface Mount
